Evergreen Lights Doheny Indoor Walls

SPECIFICATION FEATURES

Product Numbers:

DO-9-6WDO-9-12WDO-12-6WDO-12-12WDO-12-24WDO-16-12WDO-16-24W

Material

Paintlok Non Rustable Steel construction spot welded for high quality appearance in a Cutoff V Shaped Side Slotted Design, standard powdercoat finish, with white acrylic inlay for the side slots, with open top and bottom.Option: Wet Location with top and bottom lens or a solid metal cap.

Installation

Supplied with standard mounting hardware to mount to a 4” J-box or plaster ring

Optics

Contact Evergreen Lighting for complete photometrics.

LED

Alta #AL-R-1W-30 LED array to be mounted onto an Aluminum MPCB Board configured to the proper wattage.The LED arrays will be centered within the Lens area and decorative on a white aluminum reflective plate.

Driver

Specific Drivers will be matched with each different LED array configuration/ wattage. Standard Driver features are:

• Constant Current
• 5 year warranty
• 120/277 multi-voltage power supplies
• IP66, IP67
