Evergreen Lights Monterey Indoor Walls

SPECIFICATION FEATURES

Product Numbers:MO-10-6WMO-10-12WMO-13-12WMO-13-24WMO-16-12WMO-16-24W

Material

Paintlok Non Rust-able Steel construction spot welded for high quality appearance in a Three Panel Cage Design, standard powdercoat finish, white smooth acrylic flat panel lens, .125 thick, with open top and bottom.Option: Wet Location with top and bottom lens or solid metal top cap.

Installation

Supplied with standard mounting hardware to mount to a 4” J-box or plaster ring

Optics

Contact Evergreen Lighting for complete photometrics.

LED

Alta #AL-R-1W-30 LED array to be mounted onto an Aluminum MPCB Board configured to the proper wattage.The LED arrays will be centered within the Lens area and decorative on a white aluminum reflective plate.

Driver

Specific Drivers will be matched with each different LED array configuration/ wattage. Standard Driver features are:

• Constant Current
• 5 year warranty
• 120/277 multi-voltage power supplies
• IP66, IP67
