Evergreen Lights Montreal Indoor Walls

SPECIFICATION FEATURES

Product Numbers:MT-20-12WMT-20-24WMT-20-36W

Material

Aluminum Perforated Sheet construction spot welded for high quality appearance, standard powdercoat finish, white smooth acrylic inlay lens, 1/16” thick.

InstallationSupplied with standard mounting hardware to mount to a 4” J-box or plaster ring

Optics

Contact Evergreen Lighting for complete photometrics.

LED

Alta #AL-R-1W-30 LED array to be mounted onto an Aluminum MPCB Board configured to the proper wattage.The LED arrays will be centered within the Lens area and mounted on a white aluminum reflective backplate

Driver

Specific Drivers will be matched with each different LED array configuration/ wattage. Standard Driver features are:

• Constant Current
• 5 year warranty
• 120/277 multi-voltage power supplies
• IP66, IP67
