Evergreen Lights Essex Pendant Indoor Ceiling/Pendant

SPECIFICATION FEATURES

Product Numbers:

ESX-P-27-36WESX-P-27-54WESX-P-27-72WESX-P-33-72WESX-P-33-90WESX-P-33-120W

Material

Aluminum 1/2”- 3/4” round tube construction with an aluminum spun canopy for standard powdercoat finish or polished brass plated finish with P95 frosted white acrylic bowl. Decorative 3 rod design. Aluminum perforated band material for decorative trim. Maximum overall hang height for 3 rod stem assembly is 3’ (OA). Any lengths over 3’contact Factory

Installation

Supplied with standard mounting hardware to mount to a 4” J-box or plaster ring

Optics

Contact Evergreen Lighting for complete photometrics.

LED

Alta #AL-R-1W-30 LED array to be mounted onto an Aluminum MPCB Board configured to the proper wattage.The LED arrays will be centered within the Lens area and decorative on a white aluminum reflective plate.

Driver

Specific Drivers will be matched with each different LED array configuration/ wattage. Standard Driver features are:

• Constant Current
• 3 or 5 year warranty
• 120/277 multi-voltage power supplies
• IP66, IP67
