Evergreen Lights Del Rey Indoor Walls

SPECIFICATION FEATURES

Product Numbers:DR-24-8WDR-24-16WDR-36-12WDR-36-24WDR-48-16WDR-48-32W

Material

Paintlok Non-Rustable Steel construction with a Two Center Band Design spot welded for high quality appearance, solid metal end caps, standard powdercoat finish, white smooth C-Shaped acrylic lens, 1/8” thick.

InstallationSupplied with standard mounting hardware to mount to a 4” J-box or plaster ring

Optics

Contact Evergreen Lighting for complete photometrics.

LED

Alta #AL-R-1W-30 LED array to be mounted onto an Aluminum MPCB Board configured to the proper wattage.The LED arrays will be centered within the Lens area and mounted on a white aluminum reflective backplate

Driver

Specific Drivers will be matched with each different LED array configuration/ wattage. Standard Driver features are:

• Constant Current
• 5 year warranty
• 120/277 multi-voltage power supplies
• IP66, IP67
