| Engine Information | | EPA and CARB certificated | | Engine type: | 4-stroke, single cylinder, air cooled | | Displacement: | 163cc | | Max HP: | 5.5hp/3600rpm | | Max torque: | 8 lb ft/3600rpm | | Bore x stroke: | 2.6 x 1.8 inches | | | | Climbing ability: | 12 degrees | | Ignition: | C.D.I | | Starting system: | Electric Start with Pull Start Backup | | Battery: | 12V 9Ah | | Carburetor brand: | JF (RX) | | Engine oil: | SAE 15W-40 | | General Information | | Clutch: | Automatic with reverse | | Driveline / Driving wheel: | Chain / Dual wheel drive | | Suspension, F / R: | Dual A-arm / Double Oil Damped Shock | | Brakes | Disc | | Tires, F / R: | 145X70-6 / 16 X8-7 | | Fuel capacity: | 1.2 gal | | Weight, G.W. / N.W.: | 280 / 232 lbs | | Max load: | 300 lbs | | Dimension Information | | Wheelbase: | 42.6 inches | | OA L x W x H: | 58.7x38.2x48.8 inches | | Height to seat: | 13.6 inches | | Min ground clearance: | 4.02 inches | | Pedal to seat back: 30” to 35”; Pedal can also adjusted to 3” or 6” shorter. | | | | Features: Live Axle, Two-wheel Drive, Electric Start w/Pull Start Back Up, LED Headlight, Remote Start/Kill, Adjustable Sports Seat, Adjustable Pedal, Five Point Safety Seatbelt, Speed Governor, Horn, Age Group: 4-12 yrs. | |
|
|
