Evergreen Lights Yale Indoor Ceiling/Pendant

Product Number: YA-C-14-12W-MN-A

SPECIFICATION FEATURES

Product Numbers:

YA-10-8WYA-10-12WYA-14-12WYA-14-24WYA-18-24WYA-18-48W

Material

Aluminum Perforated Sheet construction spot welded for high quality appearance, standard powdercoat finish, white smooth acrylic inlay flat panels, 1/16” thick.

Installation

Supplied with standard mounting hardware to mount to a 4” J-box or plaster ring

Optics

Contact Evergreen Lighting for complete photometrics.

LED

Alta #AL-R-1W-30 LED array to be mounted onto an Aluminum MPCB Board configured to the proper wattage.The LED arrays will be centered within the Lens area and decorative on a white aluminum reflective plate.

Driver

Specific Drivers will be matched with each different LED array configuration/ wattage. Standard Driver features are:

• Constant Current
•  5 year warranty
• 120/277 multi-voltage power supplies
• IP66, IP67
