Evergreen Lights Warwick Semi Flush Indoor Ceiling/Pendant

Product Number: WAR-S-23-54W-CH-WF

SPECIFICATION FEATURES

Product Numbers:

WAR-S-16-12WWAR-S-16-18WWAR-S-16-27WWAR-S-23-24WWAR-S-23-36WWAR-S-23-54W

Material

Aluminum square solid bar construction with an aluminum spun canopy for standard powdercoatfinish or polished brass plated finish with P95 frosted white acrylic bowl. Four rod design with a separate canopy assembly for 45 degree swivel mount  (option). Maximum overall hang height for one piece stem assembly is5’ (OA). Lengths from 5’ to 25’must have a 5/8” deco connectorthat will be provided. Anylengths over 25’contact Factory

Installation

Supplied with standard mounting hardware to mount to a 4” J-box or plaster ring

Optics

Contact Evergreen Lighting for complete photometrics.

LED

Alta #AL-R-1W-30 LED array to be mounted onto an Aluminum MPCB Board configured to the proper wattage.The LED arrays will be centered within the Lens area and decorative on a white aluminum reflective plate.

Driver

Specific Drivers will be matched with each different LED array configuration/ wattage. Standard Driver features are:

• Constant Current
• 3 or 5 year warranty
• 120/277 multi-voltage power supplies
• IP66, IP67
