Evergreen Lights Vancouver Indoor Walls

SPECIFICATION FEATURES

Product Numbers:VA-9-6WVA-9-12WVA-12-12WVA-12-24W

Material

Paintlok Non Rustable Steel construction spot welded for high quality appearance in a Square Shaped Design, standard powdercoat finish, with a thin white acrylic inlay, with open top and bottom. Option: Wet Location with top and bottom lens or a solid metal cap.

Installation

Supplied with standard mounting hardware to mount to a 4” J-box or plaster ring

Optics

Contact Evergreen Lighting for complete photometrics.

LED

Alta #AL-R-1W-30 LED array to be mounted onto an Aluminum MPCB Board configured to the proper wattage.The LED arrays will be centered within the Lens area and decorative on a white aluminum reflective plate.

Driver

Specific Drivers will be matched with each different LED array configuration/ wattage. Standard Driver features are:

• Constant Current
• 5 year warranty
• 120/277 multi-voltage power supplies
• IP66, IP67
