Evergreen Lights Reno Indoor Walls

Product Number: RE-W-15-18W-CH-WF

STANDARD  FEATURES

Product Numbers:

RE-10-8WRE-10-12WRE-10-16WRE-15-12WRE-15-18WRE-15-24WRE-20-12WRE-20-24WRE-20-30W

Material

Aluminum Square Bar construction milled for high quality appearance, standard powdercoat finish, white smooth acrylic half cylinder lens, .125 thick, with open top and bottom. Option: Wet Location with top and bottom lens, or with solid metal top cap.

Insallation

Supplied with standard mounting hardware to mount to a 4” J-box or plaster ring

Optics

Evergreen Lighting Website for complete photometrics.

LED

Alta #AL-R-1W-30 LED array to be mounted onto an Aluminum MPCB Board configured to the proper wattage.The LED arrays will be centered within the Lens area and mounted on a decorative white aluminum reflective plate.

Driver

Specific Drivers will be matched with each different LED array configuration/ wattage. Standard Driver features are:• Constant Current• 3 or 5 year warranty• 120/277 multi-voltage power supplies• IP66, IP67
