Evergreen Lights Marin Outdoor Wall Architectural

Product Number: MRN-W-24W-TR-WF

STANDARD  FEATURES

Product Numbers:

MRN-W-15-12W

MRN-W-15-18W

MRN-W-15-24W

MRN-W-19-12W

MRN-W-19-24W

MRN-W-19-30W

MRN-W-24-20W

MRN-W-24-40W

Material

Paintlok non rustable steel backplate with reflective gloss white powdercoat finish, with solid flat bar front accent with standard powdercoat finish attached to a P95 white frosted acrylic half cylinder lens with top and bottom lens.

Insallation

Supplied with standard mounting hardware to mount to a 4” J-box or plaster ring

Optics

Evergreen Lighting Website for complete photometrics.

LED

Alta #AL-R-1W-30 LED array to be mounted onto an Aluminum MPCB Board configured to the proper wattage.The LED arrays will be centered within the Lens area and mounted on a decorative white aluminum reflective plate.

Driver

Specific Drivers will be matched with each different LED array configuration/ wattage. Standard Driver features are:• Constant Current• 3 or 5 year warranty• 120/277 multi-voltage power supplies• IP66, IP67
