Evergreen Lights Evolution 22 Outdoor Wall Architectural

Product Number: EVOL22-W-27-224LED-BA-WDA

STANDARD  FEATURES

Product Numbers:

22″ Size EVOL22-W-22-6LEDEVOL22-W-22-12LEDEVOL22-W-22-15LEDEVOL22-W-22-30LED27″ Size EVOL22-W-27-15LEDEVOL22-W-27-24LEDEVOL22-W-27-30LEDEVOL22-W-27-48LED32″ Size EVOL22-W-32-12LEDEVOL22-W-32-24LEDEVOL22-W-32-30LEDEVOL22-W-32-60LED44″ Size EVOL22-W-44-18LEDEVOL22-W-44-45LEDEVOL22-W-44-90LEDMaterial

Aluminum 3 Flat Bar Fin Design Trim on the top and bottom combined with 16 gage aluminum sheet backpan with mounting fireplate, standard powdercoat finish baked at 400 degrees, Premium Quality 100% virgin white acrylic vacuum formed half cylinder lens with high impact DR additive, .125 thick, with formed top and bottom lens with no seams.

Installation

Supplied with 1/4” thick black neoprene gasket sealing the fixture to the wall. Also supplied with standard mounting hardware to mount to a 4” J-box.

Power Supply

Integral LED Power Supply for 120/277 volt, High Power Factor, AC/DC to 12 volt, constant voltage, constant current, Class 2, -40 degree C starting temperature, cold weather start

Optics

Contact Evergreen Lighting for complete photometrics.

LED

22”:LED Board(1)6W– 900 Lumen(2)6W – 1800 Lumen(1)15W– 2250 Lumen(2)15W – 4500 Lumen27”:LED Board(1) 15 watt – 2250 Lumen(1) 24 watt – 3600 Lumen(2) 15 watt – 4500 Lumen(2) 24 watt – 7200 Lumen32”:LED Board(2) 6 watt – 1800 Lumen(4) 6 watt – 3600 Lumen(2) 15 watt – 4500 Lumen(4) 15 watt – 9000 Lumen44”:LED Board(3) 6 watt – 2700 Lumen(3) 15 watt – 6750 Lumen96) 15 watt – 13,500 Lumen
