Evergreen Lights Evolution 14 Outdoor Wall Architectural

Product Number: EVOL14-W-27-224LED-MBK-WDA

STANDARD  FEATURES

Product Numbers:

22″ Size EVOL14-W-22-6LEDEVOL14-W-22-12LEDEVOL14-W-22-15LEDEVOL14-W-22-30LED27″ Size EVOL14-W-27-15LEDEVOL14-W-27-24LEDEVOL14-W-27-30LEDEVOL14-W-27-48LED32″ SizeEVOL14-W-32-12LEDEVOL14-W-32-24LEDEVOL14-W-32-30LEDEVOL14-W-32-60LED44″ SizeEVOL14-W-44-18LEDEVOL14-W-44-45LEDEVOL14-W-44-90LED

Material

Aluminum Flat Bar Trim with aluminum horizontal bar design combined with 16 gage aluminum sheet backpan with mounting fireplate, standard powdercoat finish baked at 400 degrees, Premium Quality 100% virgin white acrylic vacuum formed lens with high impact DR additive, .125 thick, with formed top and bottom lens with no seams

Installation

Supplied with 1/4” thick black neoprene gasket sealing the fixture to the wall. Also supplied with standard mounting hardware to mount to a 4” J-box.

Power Supply

Integral LED Power Supply for 120/277 volt, High Power Factor, AC/DC to 12 volt, constant voltage, constant current, Class 2, -40 degree C starting temperature, cold weather start

Optics

Contact Evergreen Lighting for complete photometrics.

LED

22”:LED Board(1)6W– 900 Lumen(2)6W – 1800 Lumen(1)15W– 2250 Lumen(2)15W – 4500 Lumen27”:LED Board(1) 15 watt – 2250 Lumen(1) 24 watt – 3600 Lumen(2) 15 watt – 4500 Lumen(2) 24 watt – 7200 Lumen32”:LED Board(2) 6 watt – 1800 Lumen(4) 6 watt – 3600 Lumen(2) 15 watt – 4500 Lumen(4) 15 watt – 9000 Lumen44”:LED Board(3) 6 watt – 2700 Lumen(3) 15 watt – 6750 Lumen96) 15 watt – 13,500 Lumen
