Evergreen Lights Atlantis Ceiling Indoor Ceiling/Pendant

SPECIFICATION FEATURES

Product Numbers:

ATL-C-18-12WATL-C-18-18WATL-C-18-27WATL-C-25-24WATL-C-25-36WATL-C-25-54W

Material

Aluminum round spun trim construction for standard powdercoat finish or polished brass plated finishwith a frosted white acrylic bowl

InstallationSupplied with standard mounting hardware to mount to a 4” J-box or plaster ring

Optics

Contact Evergreen Lighting for complete photometrics.

LED

Alta #AL-R-1W-30 LED array to be mounted onto an Aluminum MPCB Board configured to the proper wattage.The LED arrays will be centered within the Lens area and mounted on a white aluminum reflective plate.

Driver

Specific Drivers will be matched with each different LED array configuration/ wattage. Standard Driver features are:

• Constant Current
• 3 or 5 year warranty
• 120/277 multi-voltage power supplies
• IP66, IP67
