Evergreen Lights Apollo Pendant Indoor Ceiling/Pendant

SPECIFICATION FEATURES

Product Numbers:

APO-P-27-36WAPO-P-27-54WAPO-P-27-72WAPO-P-33-90WAPO-P-33-120WAPO-P-33-72W

Material

Aluminum round tube construction with an aluminum spun canopy for standard powdercoat finish or polished brass plated finish with a frosted white acrylic bowl. Single stem design with a 45 degree swivel mount. Maximum overall hang height for one piece stem assembly is 5’ (OA). Lengths from 5’ to 25’ must have a 5/8” deco connector that will be provided. Any lengths over 25’ please contact Factory.

Installation

Supplied with standard mounting hardware to mount to a 4” J-box or plaster ring

Optics

Contact Evergreen Lighting for complete photometrics.

LED

Alta #AL-R-1W-30 LED array to be mounted onto an Aluminum MPCB Board configured to the proper wattage.The LED arrays will be centered within the Lens area and decorative on a white aluminum reflective plate.

Driver

Specific Drivers will be matched with each different LED array configuration/ wattage. Standard Driver features are:

• Constant Current
• 3 or 5 year warranty
• 120/277 multi-voltage power supplies
• IP66, IP67
